Product Details:
|
| Name: | Large Vertical Beverage Soy Sauce Vinegar Paste Jam Juice Fruit Pulp Shampoo Gel Auto Liquid Filling Machine | Application: | Pesticide, Shampoo, Body Lotion, Cream, Sauce, Jam, Ketchup, Honey,Juice And Other Liquid Products |
|---|---|---|---|
| Machine Material: | 304# Stainless Steel | Driven Type: | Electric |
| Controller System: | PLC | Function: | Dose, Form, Fill, Seal, Cut |
| Dosing Device: | Liquid Bump By Volume | Packaging Material: | Film |
| Film Material: | OPP, PE, PVC, OPP/CPP, OPP/PE, PET/VMPET/PE | Film Width: | <600mm |
| Sachet Making Size: | L: 150-480mm W: 100-250mm | Packing Speed: | 4-15 Bags/min |
| Power: | 380V/50Hz, 4.5kw | Air Pressure: | 0.6Mpa |
| Air Consumption: | 0.006m^3/min | Machine Weight: | 720kg |
| Machine Size: | L4200*W1100*H1587mm | Warranty: | 12 Months |
| After-sales Service: | Online Support | ||
| High Light: | Soy Sauce Vertical Liquid Filling Machine,Jam Juice Vertical Liquid Filling Machine,PLC Gel Auto Liquid Filling Machine |
||
Introduction:
It is widely used in food, medicine and chemical industries.Applicable packaging products: bean paste stuffing, lotus paste, fruits pulp, chilli sauce, salad dressing, cheese, soy sauce, liquid, peanut oil, mineral water, medical liquid etc. and automatically packaging detergent, grease and other fluid and semi-fluid products.
Features:
1.The machine can pack a variety of materials.
2. Bag length can be adjusted.
3. The machine is suitable for many specifications of bag former according to different material and weight, and it is easy to change .
4. Many types of bumps are also optional, according to material.
5. The machine can connect to the production line and can pack the product with high temperature. There are optional automatic device such as cooling equipment, blow dryer, feeding machine, conveyer belt, to ensure the product is not polluted, to enhance the efficiency.
Technical Parameters
| Model | 600# |
| Forming bag size(mm) | L:150-480 W:100-250 |
| Film material | OPP PE PVC OPP/CPP OPP/PE PET/VMPET/PE |
| Film width(mm) | 220-560 |
| Filling weight | 10-5000g |
| Packaging speed | 4-15bags/min |
| Filling volume | Max.5000cc |
| Sealing type | back sealing |
| Power | AC 380v/50hz 4.5KW |
| Pressure | 0.6Mpa |
| Air consumption | 0.06m3/min |
| Machine Weight | 720kg |
| Machine Size | L4200*W1100*H1587mm |
Large Vertical Beverage Soy Sauce Vinegar Paste Jam Juice Fruit Pulp Shampoo Gel Auto Liquid Filling Machine
Some special bag shapes are availabe:
Large Vertical Beverage Soy Sauce Vinegar Paste Jam Juice Fruit Pulp Shampoo Gel Auto Liquid Filling Machine
Q & A
Q1: Are you a factory or a trade company?
A: We are a packaging machinery manufacturer specializing in VFFS packing machine, horizontal flow packing machine, film shrink wrapper and box carton packing machine, which apply to pack liquid, powder, granules, daily products, food etc.
Q2: How can I trust you?
A: Pls find our business license, ISO certificate and SGS certificate audited by made-in-China
Q3: How to find a suitable machine for my products.
A: Pls advise what your product is( It would be better if you could provide the image or video), the unit packing weight, the bag shape and size( width + length) and other requirements. We will match the suitable machine for you .
Q4: How can you guarantee the machine quality?
A: We will list all the machine configuration ( components brand, material, specifications etc.) while doing the quotation. Before delivery, we will send you the pictures and video for you to check, or you can arrange a person to check it.
Q5:Can you explain the whole transaction process?
A: 1.Inquiry and communiate to comfirm the details and requirements.
2. Sign the contract.
3. Arrange 30% deposit to our company.
4. Factory arrange production.
5. Testing and detecting the machine.
6. Inspected by the customer.
7. Arrange the balance payment before shipment.
Q6: Is the engineer available to serve overseas?
A: Yes, but you need to pay the trip expense.
In order to save your cost, we can support via on-line video call.
