Product Details:
|
| Name: | Fully Automatic Opening Bottom Folding Sealing Carton Box Erecting Machine | Automatic Grade: | Automatic |
|---|---|---|---|
| Forming Species: | Box Molding | Forming Function: | Forming |
| Driven Type: | Electric | Warranty: | 12 Months |
| After-sale Service: | Online Support | ||
| High Light: | Automatic Bottom buckle box sealing machine,SGS box sealing machine,box carton erecting machine |
||
Application:Mainly suitable for B/E/F corrugated paper and 300-450g whiteboard paper and other packaging materials of paper boxes. Widely used in such, Digital products, cosmetics, knitted products, baked goods, toys, fruits, daily necessities, pharmaceuticals, and other industries of medium and high-grade carton packaging.
Introduction:This machine is one of our main product. It can automatically take box, push box downward, fold ears, fold page, insert card, form. It is suitable for many sizes of boxes and can adjust freely.
Features:
1.The machine is simple and easy to operate.
2.It is suitable for different size of box and it is convenient (several minutes) to adjust the machine while changing size.
3.It finishes all the function at the same time, no need to pause.
4. There is large volume for paperboard shelf, don't need to add paperboard very often.
5. There is big acrylic protection cover.
6. Bottom buckle box and glue box are optional.
Technical parameters
| Model | FJH2 |
| Speed | 18-25pieces/min |
| Ajustable Size Range | L: 130-400mm |
| W:110-380mm | |
| H:35-100mm | |
| Power | 220V, 50HZ/60HZ |
| Air Pressure | >=0.6mpa |
| Machine Size | L2600*W1350*H1800mm |
| Machine Weight | 1400KG |
Q&A
Q1: Are you a factory or a trade company?
A: We are a packaging machinery manufacturer specializing in VFFS packing machine, horizontal flow packing machine, film shrink wrapper and box carton packing machine, which apply to pack liquid, powder, granules, daily products, food etc.
Q2: How can I trust you?
A: Pls find our business license, ISO certificate and SGS certificate audited by made-in-China
Q3: How to find a suitable machine for my products.
A: Pls advise what your product is( It would be better if you could provide the image or video), the unit packing weight, the bag shape and size( width + length) and other requirements. We will match the suitable machine for you .
Q4: How can you guarantee the machine quality?
A: We will list all the machine configuration ( components brand, material, specifications etc.) while doing the quotation. Before delivery, we will send you the pictures and video for you to check, or you can arrange a person to check it.
Q5:Can you explain the whole transaction process?
A: 1.Inquiry and communiate to comfirm the details and requirements.
2. Sign the contract.
3. Arrange 30% deposit to our company.
4. Factory arrange production.
5. Testing and detecting the machine.
6. Inspected by the customer.
7. Arrange the balance payment before shipment.
Q6: Is the engineer available to serve overseas?
A: Yes, but you need to pay the trip expense.
In order to save your cost, we can support via on-line video call.
