Product Details:
|
| Name: | Automatic Small Size Vertical Flow Sachet Packing Machine For Food Products | Application: | Food,Chemical,Pharmaceutical, Other Industries. |
|---|---|---|---|
| Machine Material: | 304# Stainless Steel | Driven Type: | Electric |
| Controller System: | PLC | Accuracy: | 0.5g |
| Function: | Form ,Fill, Seal Cut | Packaging Material: | Film |
| Dosing Device: | Measuring Cup | Film Width: | <300mm |
| Cutting Type: | Round Corner/Slice Cut/Toothed Cut | Sachet Making Size: | L: 30-165mm, W: 30-150mm |
| Power: | 1P/220V/50Hz, 1.5KW | Packing Speed: | 30-80 Bags/min |
| Automatic Grade: | Automatic | Warranty: | 12 Months |
| After-sales Service: | Online Support | Customized: | Yes |
| Film Material: | OPP, CPP, PE, PET | Material Type: | Grain |
| High Light: | Small Automatic Granule Packing Machine,Food Automatic Granule Packing Machine,Flow sachet packing machine |
||
This machine can be widely applied to pack grains, seeds, pet's food, candy, raisins,drying agent, seasoning etc.
Feature
1.Small size, low cost.
The machine is featured with compact structure, durable, logical design and precise.
2.Photoelectric sensor, stepping motor control film transporting system, reliable. .
3. It can finish automaticlly all processes, such as measuring, filling, date coding, sealing, cutting.
3.Many sachet styles are optional, can also be customized.
Technical parameters
| Model | JSL-300 |
| Bag Type | Special shape, 3/4 sides seal or back side seal etc. |
| Bag Size | W: 30-165mm L:30-150mm |
| Packing Speed | 30-80 bags/min |
| Method of Measurement | Measuring cup type |
| Compressed air consumption | 6-8kg/m2 ~0.3m3 /min |
| Total Power | 1.5KW |
| Cutting type | round corner cut/ slice cut/ linked bags/ toothed cut |
| Machine Size (L*W*H) | L1661*W1160*H2291mm |
| Voltage | 220V, 50/60HZ |
Packing Samples
Cutting Type
Machine Working Flow
Machine Details
Q&A
Q1: Are you a factory or a trade company?
A: We are a packaging machinery manufacturer specializing in VFFS packing machine, horizontal flow packing machine, film shrink wrapper and box carton packing machine, which apply to pack liquid, powder, granules, daily products, food etc.
Q2: How can I trust you?
A: Pls find our business license, ISO certificate and SGS certificate audited by made-in-China
Q3: How to find a suitable machine for my products.
A: Pls advise what your product is( It would be better if you could provide the image or video), the unit packing weight, the bag shape and size( width + length) and other requirements. We will match the suitable machine for you .
Q4: How can you guarantee the machine quality?
A: We will list all the machine configuration ( components brand, material, specifications etc.) while doing the quotation. Before delivery, we will send you the pictures and video for you to check, or you can arrange a person to check it.
Q5:Can you explain the whole transaction process?
A: 1.Inquiry and communiate to comfirm the details and requirements.
2. Sign the contract.
3. Arrange 30% deposit to our company.
4. Factory arrange production.
5. Testing and detecting the machine.
6. Inspected by the customer.
7. Arrange the balance payment before shipment.
Q6: Is the engineer available to serve overseas?
A: Yes, but you need to pay the trip expense.
In order to save your cost, we can support via on-line video call.
